© National Instruments | 3-1
3
Analog Input
To perform analog input measurements, install a supported analog input C Series module into
any slot on the cDAQ chassis. The measurement specifications, such as number of channels,
channel configuration, sample rate, and gain, are determined by the type of C Series module
used. For more information and wiring diagrams, refer to the documentation included with your
C Series modules.
The cDAQ chassis has three AI timing engines, which means that three analog input tasks can
be running at a time on a chassis. An analog input task can include channels from multiple analog
input modules. However, channels from a single module cannot be used in multiple tasks.
Multiple timing engines allow the cDAQ chassis to run up to three analog input tasks
simultaneously, each using independent timing and triggering configurations. The three
AI timing engines are ai, te0, and te1.
Analog Input Triggering Signals
A trigger is a signal that causes an action, such as starting or stopping the acquisition of data.
When you configure a trigger, you must decide how you want to produce the trigger and the
action you want the trigger to cause. The cDAQ chassis supports internal software triggering,
external digital triggering, analog triggering, and internal time triggering.
Three triggers are available: Start Trigger, Reference Trigger, and Pause Trigger. An analog or
digital signal can initiate these three trigger actions. Time can also initiate the Start Trigger. Up to
two C Series parallel digital input modules can be used in any chassis slot to supply a digital trigger.
To find your module triggering options, refer to the documentation included with your C Series
modules. For more information about using digital modules for triggering, refer to Chapter 5,
Digital Input/Output and PFI.
Refer to the AI Start Trigger Signal, AI Reference Trigger Signal, and AI Pause Trigger Signal
sections for more information about the analog input trigger signals.
Analog Input Timing Signals
The cDAQ chassis features the following analog input timing signals:
• AI Sample Clock Signal*
• AI Sample Clock Timebase Signal
• AI Start Trigger Signal*
