1-26 | ni.com
Chapter 1 Getting Started with the cDAQ Chassis
Mounting the Chassis on a Rack
NI offers the following rack-mount kits that you can use to mount the cDAQ chassis and other
DIN rail-mountable equipment on a standard 482.6 mm (19 in.) rack.
• NI 9910 Sliding Rack-Mounting Kit, 779102-01
• NI Rack-Mounting Kit, 781989-01
Note You must order the NI 9912 DIN rail mounting kit, 779019-01, or NI 9915
DIN rail mounting kit, 779018-01, in addition to a rack-mount kit.
Mounting the cDAQ Chassis on a Desktop
You can use the NI 9901 desktop mounting kit, part number 779473-01, to mount the cDAQ
chassis on a desktop.
What to use:
• cDAQ chassis
• Screwdriver, Phillips #1
• Screwdriver, Phillips #2
• NI 9901 desktop mounting kit, 779473-01, containing desktop mounting brackets (x2)
