34 | ni.com | NI myDAQ User Guide
Texas Instruments Components in NI myDAQ
Integrated circuits supplied by Texas Instruments form the power and analog I/O subsystems of
NI myDAQ. Figure 2 depicts the arrangement and function of the NI myDAQ subsystems.
Table 5 lists all of the Texas Instruments components used in NI myDAQ. Visit
www.ti.com
to see the specifications documents for each of the components in the design.
Table 5. Texas Instruments Components in NI myDAQ
Texas Instruments
Integrated Circuit
(IC)
Part Number Description
Current-Limited
Power Distribution
Switch
TPS2553 This is used for applications where precision current
limiting is required or heavy capacitive loads and short
circuits are encountered.
Regulator TPS61170 This is a monolithic high-voltage boost regulator with
an integrated 1.2 A, 40 V power MOSFET.
Regulator TPS62007 The TPS6200x devices are a family of low-noise
synchronous step-down DC-DC converter that is
ideally suited for systems powered from a one-cell
Li-ion battery or from a two- to three-cell NiCd,
NiMH, or alkaline battery.
Regulator TPS62003
LDO Regulator TPS71501 These are low-dropout (LDO) voltage regulators,
offering the benefits of low noise, low-dropout
voltage, low-power operation, and miniaturized
packages.
LDO Regulator TPS76433
Digital Isolator ISO7241A This is a quad-channel digital isolator with multiple
channel configurations and output enable functions.
Shift Register SN74AHC595 This device contains an 8-bit serial-in, parallel-out
shift register that feeds an 8-bit D-type storage register.
Switch TS5A3159 This is a single-pole double-throw (SPDT) analog
switch designed to operate from 1.65 V to 5.5 V.
Operational Amplifier OPA171 This is a single-supply, low-noise operational
amplifier.
Operational Amplifier TL062C This JFET operational amplifier features high input
impedance, wide bandwidth, high slew rate, low input
offset, and input bias currents.
ADC ADS8319 This is a 16-bit, 500-kS/s analog-to-digital converter.
DAC DAC8551 This is a small, low-power, voltage output, 16-bit
digital-to-analog converter (DAC).
Reference REF3025 This is a precision, low power, low voltage dropout
voltage reference available in a small SOT23-3.
