Chapter 1 Introduction to SCXI
Getting Started with SCXI 1-10 www.ni.com
SCXI-1140 SCXI-1301 Terminal block No —
SCXI-1304 Terminal block No AC/DC coupling, switch configurable per
channel
SCXI-1305 Terminal block No AC/DC coupling signal referencing,
switch-configurable per channel, BNC
connectors
SCXI-1310 Connector and shell No Low-cost connector and shell assembly
SCXI-1141,
SCXI-1142,
SCXI-1143
SCXI-1304 Terminal block No AC/DC coupling,
switch-configurable per channel
SCXI-1305 Terminal block No AC/DC coupling, switch-configurable per
channel, BNC connectors
SCXI-1310 Connector and shell No Low-cost connector-and-shell assembly
SCXI-1160 SCXI-1324 Terminal block No —
SCXI-1161 — No terminal block—screw terminals in module
SCXI-1162/
1162HV,
SCXI-1163/1163R
SCXI-1326 Terminal block No —
SCXI-1180 SCXI-1302 Terminal block No —
SCXI-1181,
SCXI-1181K
SCXI-1300 Terminal block Yes —
SCXI-1301 Terminal block No —
SCXI-1310 Connector and shell No —
SCXI-1330 Connector and shell No —
SCXI-1200 SCXI-1302 Terminal block No —
SCXI-1520 SCXI-1314 Terminal Block
Νο
Socketedquarter-bridgecompletionresistor
perchannel,twosocketedshunt-calibration
resistors per channel
SCXI-1310 Connector and shell No —
SCXI-1530
SCXI-1531
N/A No terminal block
required
No Connect signals directly using BNC
connectors
Table 1-2. Direct-Mount Terminal Blocks (Continued)
Module
Terminal/
Connector
Block
Terminal Block or
Connector and Shell
CJC
Sensor
Other Features
