Chapter 1 Introduction to SCXI
Getting Started with SCXI 1-14 www.ni.com
SCXI Cable Assemblies
If you are using a plug-in DAQ device or DAQCard, connect it to the SCXI
chassis using one of the SCXI cable assemblies listed in Table 1-4.
Some cable assemblies have extra male breakout connectors with which
you can access unused DAQ device signals through the SCXI-1180
feedthrough panel or the SCXI-1181 breadboard module. The SCXI-1200
comes with a 1 m parallel port cable.
SCXI Multichassis System with Plug-In DAQ Device
For a multichassis SCXI system, that is cabled using an SCXI-1346 or
SCXI-1350, chassis are daisy-chained using multichassis adapters with
shielded or unshielded cables to a single plug-in DAQ device. You can
control up to eight SCXI-1000, SCXI-1000DC, or SCXI-1001 chassis with
a single AI, MIO, or DIO-24 device. Figure 1-5 shows a multichassis
configuration using the SCXI-1346 multichassis adapter.
Table 1-4. SCXI Cable Assemblies
Cable Assembly Device Connection
SCXI-1343 Screw-terminal adapter for custom
configurations
SCXI-1348 DIO-32F
SCXI-1349 MIO E Series devices with 68-pin connector
SCXI-1353 MIO E Series devices with 100-pin connector
SCXI-1354 DAQCard-1200
SCXI-1355 AT-DIO-32HS, PCI-DIO-32HS
NB5 ribbon cable with
optional SCXI-1351
PC-DIO-96/PnP
R1005050 with
optional SCXI-1351
PCI-DIO-96
