National Instruments SCXI Series Getting Started

Chapter 3 Configuring Your SCXI Hardware and Software
Getting Started with SCXI 3-18 www.ni.com
Table 3-12. SCXI-1121 Excitation Mode Jumper Configuration
Jumpers
Excitation
Channel
Voltage Mode
(Factory-Default Position)
Current Mode
0
1
2
3
W14 W15
123
W14
123
W15
123
W14
123
W15
W22 W23
123
W22
123
W23
123
W22
123
W23
W34 W35
123
W34
123
W35
123
W34
123
W35
W46 W47
123
W46
123
W47
123
W46
123
W47
