Nautilus U628 - Assembly Instructions - Part 4; Console Shroud & Seat Post Install

12
6. Install Seat Post on Frame
NOTICE: Make sure the Adjustment Knob engages the Seat Post.
Do not set the Seat Post position higher than the stop mark (STOP) on the tube.
9
10
10
STOP
5. Attach Console Pivot Shroud
16
