Navico Simrad RS100 User Manual

6
Normal 6 Navigation mode
Data input 6, M, N, O n/a
Intercom Direct call to Handset-6 n/a
7
Normal 7 Speakers config. menu
Data input 7, P, Q, R, S n/a
Intercom Direct call to Handset-7 n/a
8
Normal 8 AIS Silent mode menu
Data input 8, T, U, V n/a
Intercom Direct call to Handset-8 n/a
9
Normal 9 My channels
Data input 9, W, X, Y, Z n/a
Intercom n/a n/a
18 |
General information | RS100 / RS100-B / V100 / V100-B User Manual
Wired Handset Numeric Keys
Depending on the mode the radio is in, the numeric keys on wired handsets provide additional
functionality.
• NORMAL mode - System is in standby:
Short press enters the numeric digit (i.e. channel number).
Long Press opens a pre-determined function or menu.
• DATA INPUT mode - Entering data in a menu:
Short press enters the numeric digit. Subsequent presses enters a letter. The displayed letter is accepted
after a short pause, or on pressing a different key.
• INTERCOM mode - System is in Intercom mode:
Short press makes a direct call to another intercom station.
Key Mode Short press Long press
0
Normal 0 Hailer mode menu
Data input 0 (blank character/space)
Intercom Call all IC stations All PA announce tone
1
Normal 1 Horn mode menu
Data input 1 n/a
Intercom Direct call to Handset-1 n/a
2
Normal 2 Alarms config. menu
Data input 2, A, B, C n/a
Intercom Direct call to Handset-2 n/a
3
Normal 3 Speaker setup ON/OFF
Data input 3, D, E, F n/a
Intercom Direct call to Handset-3 n/a
4
Normal 4 Diagnostics - Handsets
Data input 4, G, H, I n/a
Intercom Direct call to Handset-4 n/a
5
Normal 5 Position display
Data input 5, J, K, L n/a
Intercom Direct call to Handset-5 n/a

Navico Simrad RS100 Specifications

General

Brand	Navico
Model	Simrad RS100
Category	Receiver
Language	English
