Recorder
• ON - Record transmitted and received VHF audio (loop recording last 60 seconds).
• OFF - Disables voice recorder.
Display
This menu allows the user to partially customize the screen information displayed, and adjust the screen
for best visibility to suit the user and operating conditions.
Time display
Select ON or OFF to display TIME.
LOC (Local Time) is displayed below the time if a UTC (Coordinated Universal Time) offset has been
entered; otherwise UTC is shown.
¼ Note: If turned ON, the display of COG/SOG is turned OFF.
Position display
Select ON or OFF to display POSITION provided from a connected GPS source. If no GPS is connected and
a manual entry has been made, the position will be displayed prefixed with an ‘M‘.
COG/SOG Display
Select ON or OFF to display COG/SOG provided from a connected GPS source.
¼ Note: If turned ON, the display of TIME is turned OFF.
Backlight
Backlight level
¼ Note: This function is also available as a Shortcut.
Select to adjust the backlight level using the
and keys. Range is 1 to 10.
Press DSC / MENU key to activate night mode (inverts display).
Network cong
Use this menu to have backlighting adjustments synchronized with other connected devices.
Network group
Set this value to the same as other Simrad/B&G devices on the NMEA 2000 network. To keep backlight
control independent, set to a value not used elsewhere.
Network oset
Set a backlight offset where the radio display can be brighter or dimmer than other devices on the
network while remaining in sync with other devices.
Select between -5 (dimmer) to +5 (brighter)
Network min level
Select a minimum level. This is to allow the backlight is always on if the network level is set too low.
Select between 0 to 5.
22 |
Radio menus | RS100 / RS100-B / V100 / V100-B User Manual
