Waterproof:
NRS-1, NRS-2: IPx5
HS100, H100, SP100: IPx7
HS40, H60: IPx7
Weight:
NRS-1, NRS-2: 2.5 kg (5.5 lbs)
HS100, H100: 1.46 kg (3.2 lbs)
SP100: 0.45 kg (1.0 lbs)
VHF Transceiver
VHF Mode: 16K0G3E (FM) / 16K0G2B (DSC)
Usable channels (country specific): International, Europe, USA, Canada, Weather
Channel spacing: 25 KHz
Frequency stability: ± 5 ppm
Frequency control: PLL
DSC mode:
Class D (Global) with dual receiver (individual CH70)
TX Deviation at 1.3K: 2.6 ± 0.26 KHz
TX Deviation at 2.1K: 4.2 ± 0.42 KHz
ATIS mode:
TX Deviation at 1.3 KHz: 1.3 ± 0.13 KHz
TX Deviation at 2.1 KHz: 2.1 ± 0.21 KHz
VHF Transmitter
Transmitter Frequency range: 156.025 - 157.425 MHz
Output power: 25 W (23 ± 2) / 1 W (0.8 ± 0.2)
Transmitter protection: Open / short circuit of antenna
Frequency error: ≤± 1.5 KHz
Max Frequency deviation: ≤± 5
Spurious & harmonics Hi/Lo: ≤ 0.25 µ W
Modulation Distortion ±3KHz: ≤ 10 %
S/N at 3KHz Deviation: ≥ 40 dB
Audio Response at 1KHz: +1 to -3dB of 6 dB/octave from 300 hz to 3 KHz
VHF Receiver
Receiver frequency range: 156.050 - 163.275 MHz
12dB SINAD sensitivity: 0.25 µV (distant) / 0.8 µV (local) 20db SINAD
sensitivity: 0.35 µV
Adjacent CH selectivity: more than 70 db
Spurious response: more than 70 db
Intermodulation rejection: more than 68 db
Residual noise level: more than -40 db unsquelched
AIS (Class-B) (NRS-2 only)
AIS mode: Class-B CS (CSTDMA)
AIS receive function: Yes, dual receivers (receive only)
AIS receive performance:
RX sensitivity: less than -107 dbm at 20% PER
Co-channel rejection: 10 db at 20% PER
Adjacent channel selectivity:70 db at 20% PER
Intermodulation response rejection: 65 db at 20% PER
Blocking: 86 db at 20% PER
AIS transmit function: Yes, single
AIS transmitter performance:
Frequency range: 161.500 to 162.025 MHz in 25 kHz
steps
Output power: 33 dbm ± 1.5 db
Channel bandwidth: 25 kHz
Modulation modes: 25 kHz GMSK for AIS TX and RX
FrBit rate: 9600 b/s ± 50 ppm (GMSK)
