RS100/B, V100/B Specications
System features
Local/Distant control: Yes
LL Position polling: Yes
Group call: Yes
Call logs: Yes - 20 individual and 10 distress
Channel naming: Yes
Handset naming: Yes
Dual watch / Tri watch: Yes
Favorite channel scan: Yes
All scan: Yes
User programmable MMSI: Yes
User programmable ATIS ID: Yes
MMSI and NAME directory: Yes - 50 vessel contacts and 20 group contacts
Software updates: Yes, via NMEA 2000
Technical
Power supply:
12 V DC battery system; negative ground
Operating voltage range: +10.8 V to +15.6 V
Nominal operating voltage: + 13.6 V DC
Low battery alert: 10.8 V DC +/- 0.25 V
Under voltage protection: <9.1 V +/- 0.25 V
Over voltage protection: >15.6 V +/- 0.25 V
Current drain:
Transmit: ≤ 6 A @ 25 W (Hi) / 1.5 A @ 1W (Lo)
Standby - RS100/V100, 1 FHS: Less than 400 mA
Standby - RS100-B/V100-B, 1 FHS: Less than 650 mA
Replacement fuse: 10 A, mini-blade type
Temperature range: -20 ˚C to +55 ˚C (-4 ˚F t o 131 ˚F)
Software version: V5.20 (at time of release)
Equipment category:
NRS-1, NRS-2: B (Protected)
HS100, H100, SP100: B (Protected)
HS40, H60: A (Portable)
VHF antenna:
Connector: SO-239 (50 ohm) x1
Antenna Type: Dipole
Antenna Gain value: 6 dBi
AIS antenna (NRS-2 only):
Connector: SO-239 (50 ohm) x1
Antenna Type: Dipole
Antenna Gain value: 6 dBi
GPS antenna connector: SMA (female) x1
Wireless connector: RP-SMA (female) x1
Compass safe distance: 0.5 m (1.5’)
NMEA 0183:
Baud rate: Selectable 38400 or 4800 BAUD
Input (RS100,V100): RMC, GGA, GLL, GNS
Input (RS100-B,V100-B): RMC, GGA, GLL, GNS,HDG, HDM,
HDT
Output (RS100,V100): DSC, DSE, MOB, VDM
Output (RS100-B,V100-B): DSC, DSE, MOB, VDM, VDO
NMEA 2000:
Yes x 1
See Chapter 13 for supported PGNs
External speaker:
Output: 5 W @ 4 ohm x 4
Recommended speaker: 4 ohm, minimum 8 W
Hailer speaker:
Output: 24W @ 4 ohm x 1
Recommended speaker: 4 ohm, minimum 30 W
