15
3. Remove the used Tipper Foil and paper core from the Tipper Unit. Pull each knob of the reel
flange/unreel flange while holding the used tipper foil or the paper core to remove.
4. Remove the used Tipper Foil from the reel hardware, then Install the empty paper core to it.
Confirm there is no gap between the paper core and the flange of the reel hardware.
• Be sure to exchange the Tipper Foil after it is sufficiently cooled down.
Caution
Paper Core
Unreel Flange Knob
Used Tipper Foil
Reel Flange Knob
Reel Hardware
Paper Core
Confirm there is no gap
between the paper core
and the Flange of reel
hardware
To Next Page
