Specifications
The following specifications may be changed without notice.
General Specifications
Name Card Printer & Embosser
Model Advantage M8
Usable card
(Allocable PVC Card)
Magnetic stripe / IC : ISO 7810 ID-1
* Height of warped card must be less than 1mm including thickness of the card.
Connection Interface
USB2.0(Full Speed) (cable 3m in length or less)
LAN 10BASE-T/100BASE-TX
Display
Liquid Crystal Display（16 digits ×1 line）Character back light
Input Hopper
Number of cassettes 2 (*Option total 5 cassettes are available.)
Number of hoppers
6 (3 hoppers per cassette)
(*When setting optional cassettes:
3 cassettes are set : 9
4 cassettes are set : 12
5 cassettes are set : 15)
Input Hopper Capacity
300 cards (50 cards per hopper)
(*When setting optional cassettes:
3 cassettes are set : 450 cards
4 cassettes are set : 600 cards
5 cassettes are set : 750 cards.)
Card Presence Detection Out of Card detection
Manual insert mode Available
Out Stacker
Output Stacker Capacity Approximately 20 cards
Card presence detection Card-full detection
Rejected Cards
Reject stacker capacity Approximately 25 cards
Card presence detection Card-full detection
Card Counter
Resettable Software counter
Non resettable Mechanical counter
Dimensions 456mm (W) x 658mm (H) x 771mm (D)
Weight
81kg（including 2 Hopper cassettes）* excluding card weight
Power voltage AC220 - 230V 3.0A 50Hz/60Hz AC100 - 120V 4.5A 50Hz/60Hz
User environment
Operating environment
Temperature 10 to 32 degrees Celsius
Humidity 20 to 65% R.H（non-condensing）
Guaranteed accuracy environment
Temperature 18 to 28
degrees Celsius
Humidity 40 to 65% R.H.（non-condensing）
Security
Key lock for Front Cover, Right side door and Top Cover (Same for all key rocks)
Software rock (Front)
Key lock for Hopper cassette (Same for all key rocks)
Applicable Standard
Safety : CE marking (Low Voltage), EMC : CE marking(EMC), FCC Class A
* About option, please contact your distributor.
