2. Clean the Card transfer rollers on the Main Transfer Unit.
Clean the two Drive Rollers (lower side) and the two Passive Rollers (upper side) while turning the knob.
Use a waste cloth or a cotton swab absorbed with Ethanol.
3. Clean the Card transfer rollers on the Vertical Rotation Unit.
Clean the Drive Roller and the three Passive Rollers while turning the white gear.
Use a waste cloth or a cotton swab absorbed with Ethanol.
Knob
Passive Rollers
Drive Rollers
Drive Roller
Gear
Passive Roller
