Chapter 5: Disassembly Procedures 5-13
2. Remove the screws (4) that secure the LCD to the bracket.
27262
LCD Assembly w/Gasket
497-0462873
3. Gently separate the LCD from the bracket and Touch Sensor.
Caution: Use care when handling the LCD Module and the Touch Sensor. These parts
must be free of finger prints and foreign debris after reassembly.
