NCR SelfServ 28 - Protection Bollards

NCR SelfServ 28 ATM Site Preparation
26 B006-6884-A000
PROTECTION BOLLARDS
If protection bollards are to be fitted they should be positioned as shown in the illustration
below. The bollards should be no wider than 102 mm (4.0 in) in diameter.
The illustration below shows the position of the bollards relative to the ‘A’ bolt holes.
front
of safe
756 mm
(29.76 in.)
251 mm
(9.88 in.)
274 mm
(10.79 in.)
216 mm
(8.50 in.)
216 mm
(8.50 in.)
281 mm
(11.06 in.)
50 mm
(1.97 in.)
60 mm
(2.36 in.)
712 mm
(28.03 in.)
AA
AA
AA
