PACKAGE DIMENSIONS
Packaged ATM
The dimensions of a packaged ATM, with and without the carton and lid, are shown
below.
Pallet, Carton and Lid
DO NOT
STACK
FRONT
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
CONTENTS WILL BE
DAMAGED
IF LAID ON SIDE
CONTENTS WILL BE
DAMAGED
IF LAID ON SIDE
THIS WAY UP
DO NOT
STACK
28
SelfServ
TM
Carton No:
AFFIX LABELS HERE
445-0715704
LPN No:
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
LIFT WITH
FORK HERE
1420 mm
(55.91 in.)
805 mm
(31.69 in.)
559 mm
(22.01 in.)
801 mm
(31.54 in.)
1405 mm
(55.31 in.)
1817 mm
(71.54 in.)
