NCR SelfServ 28 ATM Site Preparation
32 B006-6884-A000
Entry/Exit Slot Decal
There are no recesses on the facia for entry/exit decals. However, if you wish to fit your
own, the following are guidelines to the decal sizes, design and placement.
Decal Size and Design
The decals should be a maximum of 0.5 mm (0.02 in.) thick and it is recommended that
they be made from textured polycarbonate with 3M 467 High Performance MP adhesive.
Decals should provide good contrast of at least 70% between foreground (text/icon) and
background. A sans serif typeface should be used (Tiresias is recommended). The text size
should be at least 14 point, and larger where possible. Where tactile decals are required
they should be designed in line with specific country requirements.
Suggested icon designs and wording are illustrated below:
70 mm
(2.76 in.)
12 mm
(0.47 in.)
