NCR SelfServ 28 - Advert Recess; Recessed Area for Decal - with Camera Lens; Recessed Area for Decal - Without Camera Lens

NCR SelfServ 28 ATM Site Preparation
B006-6884-A000 31
Advert Recess
The following illustrations show dimensions for an advert decal that can be placed on the
front of the product depending on whether the ATM is fitted with a camera.
Recessed Area for Decal - with Camera Lens
Recessed Area for Decal - without Camera Lens
39.5 mm (1.56 in.)
R (0.35 in.)9mm
436 mm
(17.17 in.)
50 mm
(1.97 in.)
10.7 mm
(0.42 in.)
R (0.35 in.)
9mm
436 mm
(17.17 in.)
50 mm
(1.97 in.)
