4-3
Upgrades and Options
Removing the Side Panel
To install options in your system, you must remove the
external side panel.
Notice: For proper cooling and airflow, do not operate
the system with the side panel removed. Always replace
the panel before powering on the system.
!
Caution: If you are removing the side panel after the
system is set up, you must first power off the system
and all external devices. Unplug the system power cord
To remove the side panel:
1. Power off the system and ensure it is disconnected
from the ac wall outlet.
2. The side panel on the left side of the system (as
viewed from the front) is secured with three screws.
Remove the padlock (if used) and the screws (Figure
4-1, 1) securing the side panel. Save the screws for
reattaching the side panel.
3. Put one hand on the protruding handle on the back of
the panel and the other hand under the panel. Slide
the side panel toward the rear of the chassis.
4. Pull the side panel up and away from the chassis.
