4-16
Upgrades and Options
Figure 4-7. PCI and ISA Slot Locations
J3
J4
J5
J9
J6
J10
J11
ISA
ISA
ISA
ISA
PCI
PCI
PCI
INTERNAL SCSI
TERMINATION RESISTORS
Installation Considerations
Newer adapters, designed for Plug-and-Play systems,
are automatically configured by the system without any
user intervention. Older ISA adapters must be manually
configured as detailed below. Once the manual
configuration is complete, the Plug-and-Play adapters
are configured around the manually configured
adapters without causing any resource conflicts.
