4-6
REMARK
SYMBOL
COIL FORMING
-LOWER SIDE-
REMARK
SYMBOL
Mount LEAF SPRING (CRT) and
LEAF SPRING to the
PLATE,SHIELDING.
135
136
Mount CN-CE and COIL
SPRING to the PLATE,
SHIELDING.
137
138
EMC COIL’s wire pass through
under the LEAF SPRING.(both
sides.)
Don’t change the form the
LEAF,SPRING.
Inspect all wires, coils and
clampers to ensure that all leads
are dress properly and that all
clampers are closed and securely
fastened.
Don’t cross
these areas.
(DEGAUSS COIL and CORNER COIL)
LEAF
SPRING
EMC COIL’s
wire
EMF COIL
135
136
135
135
136
138
138
137
A’
B’
C’
Z
Z
C’
D’
E’
D’
E’
B’
A’
To Next Page
