2) Adjustment procedure
Adjust monitor in following steps.
a. Distortion adjustment
b. H. SIZE(MAX) adjustment
c. V. SIZE(MAX) adjustment
d. Size / Position adjustment
a. Distortion adjustment
a-1. The following menu B will appear on screen.
(Menu B)
“1 : Size / Position” : Adjustment of size and position
“2 : Distortion” : Adjustment of distortion
“3 : END” : Return to start menu screen
a-2. Select “Distortion” while menu B is displayed, and push “RETURN” key.
a-3. Input the adjustment signal that is specified as “80: TOTAL1 (1024*768(75))” on menu D.
a-4. Then, following menu will appear on monitor screen. For getting good distortion, adjust each
items on “Distortion Adjustment” with pushing “1”, “4”, “7”, “3”, “6” and “9” keys.
Note: Distortion adjustment signal may differ from another type of monitor in some cases.
In this case, use signal displayed on screen menu.
a-5. If adjustment is ended, push “RETURN” key to end the adjustment.
(Distortion data values of all preset signals are written by this operation.)
Note: Above menu may differ in some models.
Size/Position Distortion Manual Adjust Program SPSC2.EXE Version 1.00
MODEL:
1 : Size / Position FP1350-1
2 : Distortion
3 : END
No. ? _
Distortion Adjust MODEL:
FP1350-1
1 : ROTATION
2 : PARALLELOGRAM
3 : TRAPEZOID
4 : PIN CUSHION
5 : PINCUSHION BALANCE
7 : V LINEAR
8 : V LINEAR BALANCE
9 : S_WAVE
10 : W_WAVE
11 : UP CORNER
12 : UP CORNER BALANCE
13 : LOW CORNER
14 : LOW CORNER BALLANCE
15 : END No. ? _
(Menu C)
