b. H. SIZE(MAX) adjustment
b-1. Select “Size / Position” while menu B is displayed, and push “RETURN” key.
b-2. Input a signal displayed on the screen. (If signal is not displayed on the screen, use a signal
indicated horizontal maximum size adjustment section in the service manual.)
b-3. As following menu will appear on monitor screen, select “83: H_MAX” and push “RETURN” key.
(Menu D)
Meaning of each item in this menu is as follow:
From “1” to “35” : Adjust monitor on each signal
“85” : Adjust a vertical maximum size
“87” : Size / Position adjustment is ended
1:VGA350 FP1350-1
2:VGA400 SIZE/POSITION ADJUSTMENT
3:VGA480 23:98_640(70)
4:800*600(60)
5:MAC2(640*480)
27:640*480(85)
8:VESA640*480(75) 28:1600*1200(85)
9:XGA 29:800*600(85)
10:VESA800*600(75) 30:1024*768(85)
12:MAC2(832*624) 32:1600*1200(75)
13:1024*768(70) 33:VESA350(85) Select No.
34:VESA400(85) No. ? _
15: 1024*768(75)
16:1280*1024(60)
17:MAC_1152 80:TOTAL1(1024*768(75))
18:1280*1024(70)
20:1280*1024(75) 83:H_MAX
84:H_MAX2
85:V SIZE(MAX)
87:END
