6
1. Introduction
AC Input
Connect the supplied power cable’s two-pin plug here, and
plug the other end into an active wall outlet. (→ page 25)
Main Power Switch
When you plug the supplied power cable into an active wall outlet
and turn on the Main Power, the POWER indicator turns orange
and the projector is in standby mode.
(→ page 26, 38)
Terminal Panel (→ page 8)
MonauralSpeaker(7W)
Ventilation (outlet)
Heated air is exhausted from here.
Ventilation (inlet) / Filter Cover
(→ page 81)
Lamp Cover (→ page 85)
Rear Foot (→ page 31)
Spacer(blackrubber)
To fine-adjust the height of the rear foot,
remove the spacer and rotate the rear
foot to the desired height.
Rear
