NEC NP610 - Terminal Panel Features

8
1. Introduction
Terminal Panel Features
NP610/NP510/NP410/NP310/NP510W/NP410W/NP610S/NP510WS
6
87
3 321
54
910
NP405/NP305
6
87
3 321
54
9
1. COMPUTER1IN/ComponentInputConnector
(MiniD-Sub15Pin) (→ page 17, 20, 22)
2. COMPUTER2(DVI-I)INConnector(29Pin)
(HDCPcompatible)(→ page 19, 20)
 (NP610/NP510/NP410/NP310/NP510W/NP410W/
NP610S/NP510WS)
 COMPUTER2IN/ComponentInputConnector
(MiniD-Sub15Pin)(→ page 17, 20, 22)
 (NP405/NP305)
3. AUDIOINMiniJack(StereoMini)
(→ page 17, 19, 22)
4. AUDIOOUTMiniJack(StereoMini) (→ page 21)
5. MONITOROUT(COMP1)Connector(MiniD-Sub
15Pin)(→ page 21)
6. S-VIDEOINConnector(MiniDIN4Pin)
(→ page 23)
7. VIDEOINConnector(RCA) (→ page 23)
8. AUDIOInputJacksL/R(RCA) (→ page 23)
9. PCCONTROL[PCCONTROL]Port(D-Sub9Pin)
(→ page 98)
 Usethisporttoconnect aPCor controlsystem.
This enables you to control the projector using serial
communicationprotocol.Ifyouarewritingyourown
program,typicalPCcontrolcodesareonpage98.
10.LANPort(RJ-45) (→ page 24)
 (notavailableonNP405/NP305)
