3. Projecting an Image (Basic Operation)
 Correcting Keystone Distortion
Correcting Keystone Distortion
Ifthescreenistiltedvertically,keystonedistortionbecomeslarge.Proceedwiththefollowing
stepstocorrectkeystonedistortion
NOTE:
• TheKeystonecorrectioncancauseanimagetobeslightlyblurredbecausethecorrectionismadeelectronically.
• TheKeystonecorrectionrangecanbemadenarrower,dependingonasignaloritsaspectratioselection.
Adjusting with buttons on the cabinet
1. Press the  or  button with no menus displayed.
 Thekeystonebarwillbedisplayed.
MENU
EXIT
ENTER
STATUS
LAMP
AUTO ADJ.SOURCE
2. Use the  or  to correct the keystone distortion.
 Thekeystonebarwillbeclosedafteraperiodoftime.
3. Press the ENTER button.
 Thekeystonebarwillbeclosed.
NOTE:Whenthemenuisdisplayed,theaboveoperationisnotavailable.Whenthemenuisdisplayed,presstheMENUbuttonto
closethemenuandstarttheKeystonecorrection.
Fromthemenu,select[SETUP]→[GENERAL]→[KEYSTONE].Thechangescanbesavedwith[KEYSTONESAVE].(→ page 36,
68)
