2. Installation and Connections
COMPUTER 1 IN
COMPUTER 2 (DVI-I) IN
COMPUTER 2 IN
AUDIO IN
PHONE
VGA signal cable
(supplied)
IBMPCorCompatibles(Notebooktype)
orMacintosh(Notebooktype)
IBMPCorCompatibles(Desktop
type)orMacintosh(Desktoptype)
VGA signal cable (not
supplied)
DVI to VGA adapter
(supplied)
NOTE:WhentheDVItoVGAadapterisnottobeusedforanextendedperiodoftime,removeitfromtheprojector.Failuretodoso
may cause damage to the connector of the projector.
Using Two Analog COMPUTER Inputs Simultaneously
IfyouneedtousetwoanalogCOMPUTERinputssimultaneously,connectaVGAsignalcableasshownbelow.
NP405/NP305
Audio cable (not supplied)
