85
6. Maintenance
2. Remove the lamp housing.
(1)Loosenthetwoscrewssecuringthelamphousinguntilthephillipsscrewdrivergoesintoafreewheelingcondi-
tion.
 •Thetwoscrewsarenotremovable.
 •Thereisaninterlockonthiscasetopreventtheriskofelectricalshock.Donotattempttocircumventthis
interlock.
(2)Removethelamphousingbyholdingit.
FOCUS
FOCUS
Interlock
1. Remove the lamp cover.
(1)Loosenthelampcoverscrew
 •Thelampcoverscrewisnotremovable.
(2) Push and slide the lamp cover off.
M
ENU
STATUS
LAMP
AUTOADJ. SOURCE
FOCUS
M
ENU
STATUS
LAMP
AUTOADJ. SOURCE
FOCUS
CAUTION:
Makesurethatthelamphousingiscool
enough to before removing it.
