Response
 When the command succeeds
23h B1h <ID1> <ID2> 03h C5h <DATA01> <DATA02> <CKS>
Data part
Item Description
DATA01 Target
00h MODE
01h START POSITION
02h SUB INPUT / SUB INPUT 1
03h SUB INPUT 2
04h SUB INPUT 3
DATA02 Execution result
00h Ended successfully.
01h Ended with an error.
 When the command fails
A3h B1h <ID1> <ID2> 02h <ERR1> <ERR2> <CKS>
