Item Description
DATA04 Selection signal type 2
01h COMPUTER 20h DVI-D
02h VIDEO 21h HDMI
03h S-VIDEO 22h DisplayPort
04h COMPONENT 23h VIEWER(6-10)
05h Reserved for the system FFh Not Source Input
07h VIEWER(1-5)
― －
DATA05 Display signal type (effective only when DATA04 is 02h or 03h)
00h NTSC3.58 09h NTSC3.58 SQZ
01h NTSC4.43 0Ah COMPONENT(60Hz)
02h PAL 0Bh COMPONENT(50Hz)
03h PAL60 0Ch Unknown
04h SECAM 0Dh NTSC
05h B/W60 0Eh PAL-M
06h B/W50 0Fh PAL-L
07h PALNM FFh Not Video Input
08h NTSC3.58 LBX
― －
DATA06 Video mute
00h Off 01h On
DATA07 Sound mute
00h Off 01h On
DATA08 Onscreen mute
00h Off 01h On
DATA09 Freeze status
00h Off 01h On
DATA10 - 15 Reserved for the system
Information
For information about which parameters are supported, see the Appendix "Supplementary Information by
Command".
When the command fails
A0h BFh <ID1> <ID2> 02h <ERR1> <ERR2> <CKS>
