3. Projecting an Image (Basic Operation)
 Adjusting the Picture Size and Position
Usetheadjustabletiltfoot,thezoomleverorthefocusringtoadjustthepicturesizeandposition.
In this chapter drawings and cables are omitted for clarity.
Adjusting the throw angle (the height of an image)
[Tiltfoot](→ page 23)
Adjusting the left and right tilt of an image
[Rearfoot](→ page 23)
Finelyadjustingthesizeofanimage
[Zoomlever](→ page 24)
Adjusting the focus
[Focusring](→ page 24)
Adjustingthekeystonecorrection[KEYSTONE](→ page 25)
