61
5. Using On-Screen Menu
Options Function
AUTO
The projector will automatically determine the incoming signal and display it in its aspect
ratio. (→ next page)
The projector may erroneously determine the aspect ratio depending on its signal. If this
occurs, select the appropriate aspect ratio from the following.
4:3
Theimageisdisplayedin4:3aspectratio.
16:9 Theimageisdisplayedin16:9aspectratio.
15:9 The image is displayed in 15:9 aspect ratio.
16:10
Theimageisdisplayedin16:10aspectratio.
WIDE ZOOM The image is stretched left and right.
Parts of the displayed image are cropped at the left and right edges and therefore not
visible.
NATIVE The projector displays the current image in its true resolution when the incoming computer
signal has a lower resolution than the projector’s native resolution.
[Example 1] When the incoming
signalwiththeresolutionof800x600
is displayed onthe V300X/V260X/
V230X:
[Example2] When the incoming sig-
nalwiththeresolutionof800x600is
displayedontheV260/V230:
NOTE:
• Whenanon-computersignalisdisplayed,the[NATIVE]isnotavailable.
• WhenyouaredisplayinganRGBimagewith ahigher resolutionthan theprojector's native
resolutionsuchasSXGA,theimagewillbedisplayedintheprojector’snativeresolution(XGA)
evenif[NATIVE]isselected.
Sampleimagewhentheappropriateaspectratioisautomaticallydetermined
[Computersignal]
Aspect ratio of incoming signal 4:3 5:4 16:9 15:9 16:10
Sample image when the appro-
priate aspect ratio is automati-
cally determined
[Videosignal]
Aspect ratio of incoming signal 4:3 Letterbox Squeeze
Sample image when the as-
pect ratio is automatically de-
termined
NOTE:Todisplayasqueezedsignalprop-
erly,select[16:9]or[WIDEZOOM].
TIP:
• Imagepositioncanbeadjustedverticallyusing[POSITION]whenthe[16:9],[15:9],or[16:10]aspectratiosareselected.
• Theterm“letterbox”referstoamorelandscape-orientedimagewhencomparedtoa4:3image,whichisthestandardaspect
ratio for a video source.
 Theletterboxsignalhasaspectratioswiththevistasize“1.85:1”orcinemascopesize“2.35:1”formovielm.
• Theterm“squeeze”referstothecompressedimageofwhichaspectratioisconvertedfrom16:9to4:3.
