Using the Hardware 2-13
Removing the drive bay cover
4. Remove the drive as follows:
■ Using your fingers, press down on the hard disk drive
at the end closest to the connector.
■ While maintaining pressure, slide the drive towards
the front of the system.
!
CAUTION
Do not lift the drive out of the system before releas-
ing it from the system connector. Doing so can
damage the connectors.
■ Once the drive is disconnected, lift the drive up and
out of the system.
Release Latch
To Next Page
