Using the Hardware 2-25
Serial Devices
To install a serial device such as a printer or an external
modem, you need a cable with a female 9-pin connector.
NOTE
When you connect a printer, be sure to install
the appropriate printer driver through the Windows
Control Panel.
Follow these steps to connect a serial device to your NEC
Versa 4000.
1. Check that both the NEC Versa and the device power
are off.
2. Open the port cover on the back of the system and locate
the serial port.
3. Align and connect the 9-pin connector with the serial
port on the system. Secure the connection with the
screws provided.
4. Align and connect the other end of the cable to the ap-
propriate port on the device. Secure the connections with
the screws provided.
