2-24 Using the Hardware
2. Open the port cover on the back of the system and locate
the parallel port.
3. Align and connect the 25-pin parallel cable connector to
the parallel port on the system. Secure the cable with the
screws provided.
4. Align and connect the other end of the cable to the parallel
port on the device. Lock the connector clips.
Connecting a parallel printer
5. Connect the power cable to the device and a properly
grounded wall outlet.
6. Turn on power to the system and the device.
NOTE
Check that the device is online before you try
to use it. See the instructions that came with the
device for more information.
Parallel Port
