4-34
Using the Hardware
3.
Locate the two keyboard retainers, slide each one toward the outside
edge of the system and remove.
Removing the keyboard retainers
4.
Gently lift up the edge of the keyboard nearest the LCD and slide the
keyboard toward the LCD screen to release the tabs that secure it.
Be careful not to disconnect the keyboard or
keyboard cable entirely from the system.
Positioning the keyboard
