Using the Hardware 4-41
Note:
The system memory expansion slots are
also located underneath the keyboard. Therefore, if
you need to install/replace SO-DIMM modules, you
might want to do so while the system is already
disassembled.
7.
Reassemble the system as follows:
!
Lift up the keyboard and align the tabs on the front of it with the
grooves in the system.
!
Reseat the keyboard in its original position.
!
Slide the keyboard retainers back onto the system.
Reassembling the system
