Necchi Supernova - Page 99

A2 6/1/13
p(A26/l/24)
D(A 26/3/25)
025040 FDB
A 26/1/23 025040 FDB
Fig. 85
Tighten, without moving
these parts, the screw
No. 025040 FDB
on the small plate
No.
D
(A
26/1/24).
Loosen the screw No.
025040 FDB which
holds the small plate
No. D (A 26/1/7), as
indicated in Fig. 85.
Repeat for this plate
and for the contact finger
the same adjustments as explained above
(under 3 and 4).
99
