Nederman L-PAK Series User Manual

L-PAK 150, L-PAK 250
EN
3.3Electrical data
Motor
power
(kW/
hp)
Voltage
and
fre-
quency
(V)/
(Hz)
Nom.
Cur-
rent
(A)
TR1(V) S1F
Over-
load
relay
setting
(A)
F1 Re-
com.
Mains
fuses,
slow
(A)
F2 &
F3,
slow
(A)
F4,
fast (A)
F5,
slow
(A)
F6,
fast (A)
L-PAK 150
3.0/4.0 230/50 11.8 230 11.8 25 See wiring diagram
3.5/4.7 230/60 12.4 230 12.4 25 See wiring diagram
3.5/4.7 380/60 8.2 400 8.2 16 See wiring diagram
3.0/4.0 400/50 6.8 400 6.8 16 See wiring diagram
3.5/4.7 460/60 7.2 460 7.2 16 See wiring diagram
3.45/4.6 575/60 5.4 575 5.4 16 See wiring diagram
L-PAK 250
5.5/7.4 230/50 22.5 230 22.5 35 See wiring diagram
6.3/8.5 230/60 23.6 230 23.6 35 See wiring diagram
6.3/8.5 380/60 13.2 400 13.2 20 See wiring diagram
5.5/7.4 400/50 12.5 400 12.5 20 See wiring diagram
6.3/8.5 460/60 13.2 460 13.2 20 See wiring diagram
6.3/8.5 575/60 9.2 575 9.2 16 See wiring diagram
