www.nektartech.com Nektar Aura Owner‘s Manual 7
9 [Internal], [Lock], [Menu], [Seq], [Repeat] and [DAW] Buttons
The 4 buttons [Internal], [Seq], [Repeat] and [DAW] are mode buttons. [DAW] is only available when Nektar DAW Integration
is running. [Menu] is active when applicable to current mode selection and [Lock] is only used with Nektarine.
10
Display buttons
Four contextural buttons operate as indicated by the display labels above.
11
TFT Color Display
12
Power On/O
13
Power Supply Socket
9V / 600mA, center positive, 2.1mm barrel connector (PSU optional and not included).
14 USB Connector
Connect to USB host/computer. Aura is powered via USB.
15
Footswitch sockets 1/2
A TRS 1/4” jack socket allows connection of up to 2 external footswitch pedals.
16 MIDI Din Output Jack
Connect external MIDI equipment or use as a USB MIDI Out interface.
17
Kensington Lock
121314151617
