Nellcor N-20 - N-20 P: Loading Printer Paper

N-20P: Loading Printer Paper
1. Remove paper cover.
Set-up
Figure 5: Removing Paper Cover
2. Hold roll in palm as shown, hold paper end stiffly between
thumb and fingers. Push paper end firmly into slot
approximately 1 inch. Continue holding paper.
3. Press button on front to power up N-20.
4. Keep pushing paper into slot and hold down ADV button
(on top).
13
