Neox crosser - The E-bike Display; Display Indicators and Controls

NEOX User manual - Edition 03-201626
THE DISPLAY
1. Assistance setted up
2. Power string
3. Gear
4. Speed
5. Battery state string
6. Hour – Daily Km – Total Km – Autonomy Km
7. Button ON-OFF
8. Button UP
9. Button DOWN
10. Button enter/confirmation
11. Red Led
12. Yellow Led
13. Green Led
11
12
13
7 8 9
10
6
1 2 3 4 5
Light starting
Selection
of transmission
gear
General informations
Selection of
assistance mode
UP
Selection of
assistance mode
DOWN
Selection
of transmission
gear
