WARNING: : DO NOT CONNECT BDM-800 TO THE UTILITY GRID OR ENERGIZE THE AC CIRCUIT(S) UNTIL YOU HAVE COMPLETED ALL OF
THE INSTALLATION PROCEDURES AS DESCRIBED IN THE FOLLOWING SECTIONS.
Installing the BDM-800 Micro inverter System involves several key steps:
● Measuring service and installing the AC branch circuit junction box.
WARNING: ONLY USE ELECTRICAL SYSTEM COMPONENTS APPROVED FOR WET LOCATIONS
● Attaching the BDM-800 Micro inverter to the racking.
● Connecting the BDM-800 Micro inverter daisy chain connections
● .Grounding the system (optional)
1
● Completing the BDM-800 Micro inverter installation map and connecting the PV modules.
The finished system should be similar as in the diagram. Detailed installation steps are listed in the following
section.
1
DC circuits of BDM-800 are isolated and insulated from ground. An integrated grounding protection circuit is included in the micro inverter.
4. 5 Install the AC Branch Circuit Junction Box
Modified 04/13/2023 by JMB
