Saturn Bt – Chapter 1. Getting Started 1.9
Mounting the Antenna Cont’d
Antenna Assembling Cont’d
5 Feeder reflector
Fasten the reflector on top of the
feeder by means of the knurled
screw.
6 Remove remaining
equipment from case.
7 Close lid and tighten
upper Mounting Rod
fastening screw.
8 Place Transceiver on
case lid.
9 Continue to "Connecting
Up" on next page.
