Nescafe C70 - Page 83

Prodigio service manual Version 1.0 en
106
EXPLOSION DRAWINGS AND PARTS LISTS
26 NES-29924-SP Connector Clip
27 NES-29145-SP High Pressure Connector Assem-
bly
28 NES-29907-SP O-Ring 3.4 x 1.9 mm
29 NES-29241-SP Pump Isolation
30 NES-300330-1-SP Pump EN4FM 220-240V
30 NES-300330-2-SP Pump EN4FM 120V UL
30 NES-300330-3-SP Pump EN4FM 100-110V
30 NES-300330-4-SP Pump EN4FM 120-127V IEC
31 NES-29238-SP Pump Support Spring
32 NES-29401-SP Low Pressure Connector Pump
33 NES-29123-SP BU Housing with Pyramide Plate
34 NES-29301-SP Steam Cover
35 NES-29143-1-SP TB Assembled 220-240V TB+Triac assembled
35 NES-29143-2-SP TB Assembled 120V UL TB+Triac assembled
35 NES-29143-3-SP TB Assembled 100V TB+Triac assembled
35 NES-29143-4-SP TB Assembled 120V IEC TB+Triac assembled
36 NES-29242-SP TB Sleeve
37 NES-29908-SP O-Ring Seal TB Tube
38 NES-34120-02-SP Capsule Cage with Motor UMILK Assembled with Blade +
Capsule Cage Assy. + Motor
+ Worm Gear
39 NES-29902-SP Li Screw In6rd M3x20
40 NES-46222-SP Cover Screw
41 NES-29124-52-SP Gear Lever Left Assembly with Slide Bearing
42 NES-29915-SP OTTER Connector
43 NES-93272 Aeroccino 3-Milkfrother (SP 240)
43 NES-93269 Aeroccino 3-Milkfrother (SP 220)
43 NES-93268 Aeroccino 3-Milkfrother (SP 120)
44 NES-29307-SP Gear Wheel
45 NES-29910-SP Circlip D = 7 mm
47 NES-29125-52-SP Gear Lever Right Assembly with Slide Bearing
48 NES-29509-1-SP Connection Cable EU compl.
assembled
48 NES-29509-2-SP Connection Cable CH compl.
assembled
48 NES-29509-3-SP Connection Cable UK compl.
assembled
48 NES-29509-4-SP Connection Cable AU compl.
assembled
48 NES-29509-5-SP Connection Cable IL compl.
assembled
48 NES-29509-6-SP Connection Cable AR compl.
assembled
48 NES-29509-7-SP Connection Cable ZA compl.
assembled
Pos. No. Part No. Component Remark
