Nescafe C70 - Page 84

Version 1.0 en Prodigio service manual
107
EXPLOSION DRAWINGS AND PARTS LISTS
48 NES-29509-8-SP Connection Cable KR compl.
assembled
48 NES-29509-9-SP Connection Cable CL compl.
assembled
48 NES-29509-10-SP Connection Cable CN compl.
assembled
48 NES-29510-SP Connection Cable UL compl.
assembled
48 NES-29513-SP Connection Cable JP compl.
assembled
48 NES-29512-SP Connection Cable BR compl.
assembled
48 NES-29511-SP Connection Cable TW compl.
assembled
48 NES-34530-1-SP Connection Cable EU compl.
assembled
48 NES-34530-2-SP Connection Cable CH compl.
assembled
48 NES-34530-3-SP Connection Cable UK compl.
assembled
48 NES-34530-4-SP Connection Cable AU compl.
assembled
48 NES-34530-5-SP Connection Cable IL compl.
assembled
48 NES-34530-6-SP Connection Cable AR compl.
assembled
48 NES-34530-7-SP Connection Cable ZA compl.
assembled
48 NES-34530-8-SP Connection Cable KR compl.
assembled
48 NES-34530-9-SP Connection Cable CL compl.
assembled
48 NES-34530-11-SP Connection Cable SG compl.
assembled
48 NES-34531-1-SP Connection Cable BR compl.
127V W label
48 NES-34531-2-SP Connection Cable BR compl.
220V W label
48 NES-34534-SP Connection Cable UL compl.
assembled
49 NES-29402-SP Pump Support
51 NES-29147-SP Spring Packet
53 NES-46132-SP Light Guides (LG) Including LG Front Light / 2 x
LG Capsule Container / LG
Slider Close / Maintenance
LG
54 NES-46561-SP Keymat MMI
61 NES-46558-SP Cover Front Light
Laser Engraved
62 NES-46559-SP Lens
63 NES-46227-SP Light Guide Rack
Pos. No. Part No. Component Remark
