PROGRAMMING
NESS D16 (V4.6) CONTROL PANEL - INSTALLER MANUAL
TAMPER ALARM / OUTPUT MAPPING
This option selects which outputs will trigger when a Tamper Alarm occurs.
PROGRAMMING SEQUENCE:
P61E 1E-4E toggles the options ON and OFF
P61E 1E: Tamper Alarm to Reset output
P61E 2E: Tamper Alarm to Strobe output
P61E 3E: Tamper Alarm to Keypad Sonalert output
P61E 4E: Tamper Alarm to Siren output
P61E 1E-4E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
1E-4E, ON: Tamper alarm triggers all
outputs
NOTES:
• A Tamper Alarm can be caused by the
TAMP input or by removing the the J1
link.
KEYPAD PANIC ALARM / OUTPUT MAPPING
This option selects which outputs will trigger when a Keypad Panic alarm
occurs.
PROGRAMMING SEQUENCE:
P61E 5E-8E toggles the options ON and OFF
P61E 5E: Keypad Panic Alarm to Reset output
P61E 6E: Keypad Panic Alarm to Strobe output
P61E 7E: Keypad Panic Alarm to Keypad Sonalert output
P61E 8E: Keypad Panic Alarm to Siren output
P61E 5E-8E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
5E-8E, ON: Panic alarm triggers all outputs
NOTES:
• A Keypad Panic Alarm can be caused by
the PANIC keys on the keypad (* E or **
together, depending on Option P64E6E).
1E 2E 3E 4E 5E 6E 7E 8E
ON = Factory default setting.
Tamper to Reset output
Tamper to Strobe output
Tamper to Sonalert
Tamper to Siren output
KP Panic to Reset output
KP Panic to Strobe output
KP Panic to Sonalert
KP Panic to Siren output
OPTION No DESCRIPTION
P61E Tamper & Panic alarms mapping ON ON ON ON ON ON ON ON
