PROGRAMMING
NESS D16 (V4.6) CONTROL PANEL - INSTALLER MANUAL
CONTACT ID + AUDIBLE DTMF FORMAT
For simultaneous Central Station and Audible Monitoring.
The alarm message will be sent to the Central Station on the Primary telephone
number and then in audible DTMF format to the Follow Me telephone number.
PROGRAMMING SEQUENCE:
P86E 5E turns the option ON
P86E 5E ON: Contact ID + Audible DTMF format enabled
P86E 5E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
OFF
NOTES:
• Only one option in the range
P86E 1E—6E is allowed to be ON
CONTACT ID + AUDIBLE PULSE FORMAT
For simultaneous Central Station and Audible Monitoring.
The alarm message will be sent to the Central Station on the Primary telephone
number and then in audible PULSE format to the Follow Me telephone number.
PROGRAMMING SEQUENCE:
P86E 6E turns the option ON
P86E 6E ON: Contact ID + Audible PULSE format enabled
P86E 6E
PROGRAM MODE LEVEL:
Installer, Remote by PC
FACTORY DEFAULT:
OFF
NOTES:
• Only one option in the range
P86E 1E—6E is allowed to be ON
The D16 reports alarms to the
Central Station using Contact ID
dialler format.
The message format is fixed as
shown in the Contact ID Codes
Table.
THE MESSAGE TAKES THE FORM OF:
ssss Client Code 0000 - 9999
Q = 1 New Event or Open
Q = 3 Restore or Close
dd User ID (1 to 15)
zz Zone ID (1 to 16)
aa = 01 Area 1
aa = 02 Area 2
aa = 01 Monitor area
aa = 00 24 Hr Area
k Checksum (0 to 0f hex)
CONTACT ID CODES TABLECONTACT ID CODES TABLE
CONTACT ID CODES TABLECONTACT ID CODES TABLE
CONTACT ID CODES TABLE
REPORT NAME PREFIX Q XYZ GG CCC SUFFIX
Zone 1– Zone 16 Alarm ssss 18 q 130 aa 001–016 k
Duress ssss 18 1 121 01 030 k
Keyswitch Panic ssss 18 1 120 01 031 k
Keypad Panic ssss 18 1 120 01 032 k
Radio Key Panic ssss 18 1 120 01 1dd k
Medical Alarm ssss 18 1 100 01 033 k
Fire ssss 18 1 110 01 034 k
Exit Install mode ssss 18 1 306 01 035 k
External Tamper ssss 18 q 137 01 040 k
Internal Tamper ssss 18 q 137 01 041 k
Keypad Tamper ssss 18 q 137 01 042 k
Radio Sensor Supervision ssss 18 q 381 01 4zz k
Radio Sensor Tamper ssss 18 q 383 01 2zz k
Radio Sensor Low Battery ssss 18 q 384 01 3zz k
Mains Fail ssss 18 q 301 01 050 k
Panel Battery Fail ssss 18 q 309 01 051 k
Open ssss 18 1 402 aa 0dd k
Force Open (Cancel) ssss 18 1 406 aa 0dd k
Close ssss 18 3 402 aa 0dd k
Test Report ssss 18 1 602 01 063 k
Zone 1-16 Manual Exclude ssss 18 q 573 aa 001-008 k
Zone 1-16 Auto Exclude ssss 18 q 380 aa 001-008 k
