NESS D16 (V4.6) CONTROL PANEL - INSTALLER MANUAL
The NESS D16 is a wholly Australian Designed and Manufactured product from
Ness Security Products Pty Ltd, Australia's largest manufacturer of quality electronic
security products. Ness Security Products Pty Ltd is a Quality Accredited Company
to ISO 9001.
The Ness D16 alarm control panel has been designed to provide you, the security
professional, with a 16 zone hardwired and wireless control panel featuring ease of
installation, ease of programming and user friendly operation in a package which is
functional and attractive. The design and build of this product is based on the Ness
philosophy of excellence without compromise.
INTRODUCTION
D16 FEATURES
• 8 or 16 Fully programmable zones
• Any combination of 8 or 16 hardwire
or radio zones
• Full radio supervision
• Contact ID Dialler Format
• Ultra-Modern and Impact resistant
Housing
• Ness Audible Dialler Format
• "Follow Me" Audible Dialler Option
• Separate 24 Hour Tamper input
• Single or Double Trigger Zones
• Remote LCD Keypads (Max 3)
• Fully programmable via the system
Keypad - Eliminates the need for
expensive programmers or Proms.
• Inbuilt Vibration Sensor Analyser
• All programming data is permanently
stored in a non-volatile EEprom
memory
• Windows based Up\Down load
Software allows remote programming
and event status
• True Dynamic Battery Test every time
the Panel is armed / disarmed and
every hour
• Area Partitionable (2 Areas). Any
Zone can be programmed to any
area, as well as common areas
• Comes complete with an AC plug
pack and supports a 12V 7Ah battery
to maintain systems security under all
power supply conditions
• Monitor Mode (Home Mode)
• Outputs are separately fused with
Automatic Reset Fuses
• Day Zone feature.
• Temporary Day Zone feature.
• Zone inputs can be split with two
end-of-line resistors so that two
detection devices (ie reed switches)
can both be monitored to provide
maximum security
• 30 Event Memory
• Supports 16 Radio Devices (Radio
PIRs, Radio Reeds etc)
• Supports 14 Radio Keys
• All inputs and outputs are heavily
protected against lightning and high
voltage supply transients. An earth
terminal is provided for extra protec-
tion
• 15 User Codes
• ‘Arm only’ codes can be programmed
• Programmable Inputs to activate
selectable Outputs
• Designed utilising the latest SMD
Technology
• Simple to Program and Use.
Version History
V4.6
• New Feature - Temporary Day Zones.
• Enable or Disable Day Zones from operating mode.
• Dialler Client Codes for transmission to a central station can be entered in HEX.
• Mains fail alarm can be disabled.
• Test report clock can be programmed to use the internal oscillator for timing.
• Zones can be selected not to flash the Memory icon.
• RK4 Radio Key AUX button can be mapped to the D8/D16 Aux2 output.
V4.5
• Monitor Arming By Radio Key. Pressing the ON button twice can now be used to enter
MONITOR mode. This addition was done to allow MONITOR mode arming using a
RADIO keypad.
• Test Call Timing. When sending Test Calls, the time between dialling attempts is
increased to 60 minutes for the 2nd round of dialling.
• Arming from Monitor Mode. Arm Only codes can arm the panel directly from Monitor
Mode. (Normal user codes can arm only from the disarmed state.)
• Strobe Timeout. Strobe output will time out after 72 hours. This stops continuous strobe
operation when the alarmed premises are vacant for long periods.
• Software Version. The software version of the panel is displayed in Program mode by
entering P99999999E (eight 9’s).
